A-6051-M

This unique head gasket has a solid steel core supported by a heavy-duty,

high-densitygasket ing material coated with silicone

Additional high temperature silicone bands surround all water passages

A. Our Model A engine gasket is specifically designed for use with an original, stock Model A head.

B. This modern cylinder head gasket may be used due to its design

cannot be used with high compression cylinder heads

C. Do not use anygasket ant when using thesegasket s!

Using additionalgasket ing material may damage the two special types of siliconegasket s on thegasket ing surface

D. The side of thegasket marked "This side up" must face up.

The side with the logo must face the block.

E. Before installation, both mating surfaces should be machined or completely flat,

to be within specific factory tolerances and free of grease, oil or solvents.

All threads on the block, bolts and nuts must be clean and in good condition.

Installation instructions:

Tighten the cylinder head bolts starting from the inside out.

Tightening torque 75 Nm (55 foot pounds)

Tighten the cylinder head before driving

1) Allow the engine to warm up slowly for 15-20 minutes.

Allow the engine to cool overnight or until it is cold

(at least 6 hours)

2) Tighten the cylinder head in the correct order to 75Nm (55) food pounds

3) Repeat steps 1 and 2 after 100 miles of operation
